WARNING!
This page is still under construction. The information on it is not up-to-date.

Provides the highest quality of digital voice communication and loseless interoperability between networks with different bandwidth, providing two-layer encoding at 700 bps (basic layer) + 900 bps (extension layer) = 1600 bps bit rate total.

It's ideal for Digital Voice in HF radio at 700 and 1600 bps, as well as in VHF/UHF radio, supporting both or just the 1600 bps bit rate. This ensures the highest voice quality in each network and maintains lossless interoperability between them. Transcoding is not needed, which saves significant computational resources in gateways and also means no degradation in speech quality, even when users interoperate at different bit rates.

TWELP vocoder enables cutting the bitrate in half compared to current standard solutions while maintaining high speech quality in conditions with a lower SNR (3-7 dB lower). It also enables doubling the number of channels in VHF/UHF radio without compromising voice communication quality.

For Digital Voice in HF, VHF/UHF Radio, Digital Mobile Radio (DMR) and other markets.

TWELP Technology Features.
The vocoder is based on the newest technology of a speech coding called "Tri-Wave Excited Linear Prediction" (TWELP) that was developed by experts of DSPINI.

TWELP technology is a new class of vocoders that differs from any other LPC-based vocoders in:

• an advance reliable method of pitch estimation
• a pitch-synchronous analysis
• an advance tri-wave model of excitation
• newest quantization schemes
• a pitch-synchronous synthesis

Thanks to these unique features, TWELP technology provides much better speech quality in comparison with any well-known technologies, including AMBE+2, MELPe, ACELP, etc. at the same bit rate in range from 300 bps up to 9600 bps and beyond. Moreover, in contrast to other LBR vocoders (like MELPe, etc.) TWELP provides much better quality for non-speech signals like sirens, background music, etc.

Superiority In Speech Quality.
Here's the comparative analysis between the TWELP 700/1600 scalable vocoder and standard MELPe vocoder, which operates at 1200 and 2400 bps bit rates.
TWELP at 700 bps bit rate is compared with MELPe at 1200 bps, and TWELP at 1600 bps is compared with MELPe at 2400 bps.
The ITU-T P.50 speech database for 20 different languages was utilized, and the ITU-T P.862 utility was employed to estimate speech quality in PESQ terms.

Speech Samples (WAV-files).
Several independent experts listened to the TWELP 1200/2400 scalable vocoder in comparison with MELPe and AMR vocoders that operated at twice the higher bit rates, using a method of preferences.
Despite the objective estimations of speech quality in PESQ terms being approximately the same, the majority of experts preferred TWELP over the standard vocoders especially for low bit rate, noting a much more natural human-sounding voice in the TWELP vocoder.
You can listen to short samples of the source speech as well as the speech processed by each pair of vocoders for any of the 20 languages in the table below.
Additionally, you can download a full set of P.50 samples as zip-files for all languages simultaneously in the Downloads section below.

Superiority In Quality Of The Non-speech Signals.
In contrast to other LBR vocoders (MELPe, AMBE+2, etc.), TWELP vocoders provide a high quality of non-speech signals, including police, ambulance, fire sirens, etc. This feature in conjunction with a high quality natural human-sounding of the voice makes TWELP vocoders well suitable for replacement of analog radio with a digital radio and also for other applications where a high quality transmission of non-speech signals is relevant along with a high quality transmission of speech signals.

High Robustness To Acoustic Noise.
In contrast to other LBR vocoders, TWELP vocoders are well robust to acoustic noise thanks to robust reliable method of pitch estimation and other features of TWELP technology.

Moreover, vocoder includes in-built Noise Cancellation—Speech Enhancement (NCSE) functionality that improves a speech quality in a noisy acoustic environment.

High Robustness To The Channel Errors.
The diagram illustrates how the sensitivity of the bits in the vocoder output is affected by errors.

The first part (56 bits) represents the basic layer, while the second part (72 bits) represents the extension layer of the scalable vocoder.

We strongly recommend using FEC (Forward Error Correction) with unequal protection of the bits in strong accordance with their sensitivity to errors and utilizing 'Soft Decisions' decoding. This will provide the highest robustness of the vocoder against errors in the channel.

Additional Functionalities.
The following additional functionalities are developed by DSPINI and integrated into TWELP vocoders:

• Automatic Gain Control (AGC),
• Noise Cancellation for Speech Enhancement (NCSE)
• Voice Activity Detector (VAD),
• Tone Detection/Generation (Single tones and Dual tones). The tones are transmitted by the vocoder facilities.

Each functionality has unique features, performance and characteristics, providing a significant superiority over any well-known implementations on the market.

Technical Characteristics And Resource Requirements:

* DSPINI continues optimization of the TWELP algorithm and the code in order to minimize a computational complexity of the vocoder.
For use cases, where consumption resources are critical, we can reduce MIPS as well as memory, but with minor decreasing of speech quality.

Vulnerability / Security.
DSPINI guarantees an ABSOLUTE cleanliness of the software from any undocumented features, undeclared capabilities, etc. All our customers can be assured that any our software/code doesn't contain any secret functions or features hidden from the user. We are ready to provide the source codes of our software products for an appropriate certification if needed.

Guarantee And Support.
DSPINI guarantees a quality and accordance of all technical characteristics of the product to the requirement of the current specifications. Testing and the other method of quality control are used for a guarantee support.

Any Platforms.
DSPINI can port this vocoder software onto any other DSP, RISC or general-purposes platform in a short time: 1-2 months.

Licensing Terms.
To use the vocoder software, a customer should obtain a license from DSPINI only.

Customization.
The vocoder can be customized under any specific requirements - other bit rate, frame size, any other robustness to channel errors, etc. Please contact us for the details.

Prospects.
DSPINI is impoving and developing continuously a set of new vocoders with the range from 300 bps up to 9600 bps, based on TWELP technology.

Related Software.
This vocoder may be effectively used in a bundle with other DSPINI's products:

• Linear and acoustic echo cancellers,
• Multichannel noise cancellers (including two-microphone adaptive array),
• Wired or radiomodems for any types of channels and bitrates,
• Other products.
